Membrane Filter Hydrophobic PTFE 0.10 25mm 100/PK T010A025A

Membrane Filter PTFE(UNSUPPORTED) 0.10 25mm 100/PK

SKU: T010A025A

Manufacturer: Advantec

Pack Size: 100

Hydrophobic PTFE

properties: Thin , highly porous, behaves as an absolute retentive membrane
inert to most chemicdally aggressive solvents, strong acids and bases
Operating Temperature Range : -120'C ~260'C
Autoclavable

Applications

Sterilize gases: trap aqueous aerosols
Air and gas venting: allow gases to pass freely while Blocking aqueous liquids, protect vacuum pumps and critical samples
Sterilize and clarity strong acids and many other solvents incompatible with other membranes

Pore Size (µm)	*Bubble Point 1**		*Flow Rates 2**		*Porosity 3 (%)**	Maximum Operating Temperature (°C)	Thickness (µm)
Pore Size (µm)	MPa	psi	Acetone (mL/min/cm2)	Air (L/min/cm2)	*Porosity 3 (%)**	Maximum Operating Temperature (°C)	Thickness (µm)
0.10	³0.12	³17.4	27.0	-	68	260	70
0.20	³0.091	³13.2	55.0	-	74	260	80
0.50	³0.063	³9.1	100	-	78	260	75
0.80	³0.039	³5.7	200	-	76	260	75
1.00	³0.031	³4.5	300	-	79	260	75
3.00	³0.013	³1.9	750	-	83	260	75

HYDROPHOBIC PTFE – NON-STERILE

Plain White discs

Pore Size (µm)	Diameter
	13 mm	25 mm	47 mm	90 mm	142 mm	293 mm
	Package of 100			Package of 25		Package of 10
0.10	T010A013A	T010A025A	T010A047A	T010A090C	T010A142C	T010A293D
0.20	T020A013A	T020A025A	T020A047A	T020A090C	T020A142C	T020A293D
0.50	T050A013A	T050A025A	T050A047A	T050A090C	T050A142C	T050A293D
0.80	T080A013A	T080A025A	T080A047A	T080A090C	T080A142C	T080A293D
1.00	T100A013A	T100A025A	T100A047A	T100A090C	T100A142C	T100A293D
3.00	T300A013A	T300A025A	T300A047A	T300A090C	T300A142C	T300A293D

Attribute name	Attribute value
Pack Size	100
Media	PTFE
Diameter	25mm
Pore Size	0.1um
Surface	Plain
Colour	White
Type	Non-Sterile
