Membrane Filter MCE 0.80 WP 47mm 100/PK W/O SORBIT A080X047A

Membrane Filter MCE 0.80 WP 47mm 100/PK W/O SORBIT

SKU: A080X047A

Manufacturer: Advantec

Pack Size: 100

Mixed Cellulose Esters (MCE)

- Composition: Mixed Cellulose esters including cellulose nitrate and cellulose acetate, also known as nitrocellulose

- High porosity provides superior flow rates

- High protein binding can be blocked by pretreatment or utilized in applications

- High purity: Triton-free

- Autoclavable: Withstands autoclaving temperatures up to 130'c without adversely affecting bubble point, flow rate, or microbiological recovery

- Rapid wetting time: <3 seconds to wet a 47mm diameter disc with aqueous 1% methylene blue

MIXED CELLULOSE ESTERS – NON - STERILE

Gridded White, package of 100 discs

Pore Size (µm)	Diameter
Pore Size (µm)	13 mm	25 mm	37 mm	47 mm
0.45	A045B013A	A045B025A	A045B037A	A045B047A
0.80	A080B013A	A080B025A	A080B037A	A080B047A

Sheets, Gridded White

Pore Size (µm)	Qty/pkg	Size
Pore Size (µm)	Qty/pkg	300 mm x 300 mm
0.45	25	A045B304C

Hydrophobic Edge, 47 mm discs, package of 100 discs

Pore Size (µm)	Surface
Pore Size (µm)	Plain	Grid
0.20	A020J047A	A020K047A
0.45	A045J047A	A045K047A

Opticlear, package of 100 discs

Pore Size (µm)	Surface	Diameter
Pore Size (µm)	Surface	25 mm	37 mm	47 mm
0.80	Plain	A080X025A	A080X037A	A080X047A
0.80	Grid	A080X025B	A080X037B	A080X047B

Black, package of 100 discs

Pore Size (µm)	Surface	Diameter
Pore Size (µm)	Surface	13 mm	25 mm	37 mm	47 mm
0.45	Plain	A045N013A	A045N025A	A045N037A	A045N047A
0.45	Grid	A045P013A	A045P025A	A045P037A	A045P047A
0.80	Plain	A080N013A	A080N025A	-	A080N047A
0.80	Grid	A080P013A	A080P025A	-	A080P047A

Green, package of 100 discs

Pore Size (µm)	Surface	Diameter
Pore Size (µm)	Surface	13 mm	25 mm	47 mm
0.45	Plain	A045U013A	A045U025A	A045U047A
0.45	Grid	A045V013A	A045V025A	A045V047A
0.80	Grid	-	-	A080V047A

Applications

-Standard membranes for many laboratory applications including filter sterilizing biological fluids, microbiology, contamination analysis, and air monitoring

- Can be transparentized to view collected particles

1) using compatible liquid(immersion oil, toluene)

2) Select Opticlear membranes for the 'hot block' acetone vapor method

- Gridded filters available for quantifying microbial growth

-Available non-sterile or sterilized by ethylene oxide (EtO)

Pore Size (µm)	Color	Surface	*Bubble Point1**		*Flow Rate2**		*Porosity3 (%)**	Thickness (µm)
Pore Size (µm)	Color	Surface	MPa	psi	Water (mL/min/cm2)	Air (L/min/cm2)	*Porosity3 (%)**	Thickness (µm)
0.10	White	Plain	³0.24	³35.3	2.7	0.67	65	110
0.20	White	Plain	³0.37	³54.5	17.5	2.4	73	133
0.30	White	Plain	³0.28	³41.2	30	3.7	75	140
0.45	White	Plain	³0.24	³35.0	45	5.0	78	145
0.45	White	Grid	³0.16	³24.2	80	8.0	79	142
0.65	White	Plain	³0.14	³21.3	120	11.2	79	150
0.80	White	Plain	³0.11	³16.4	165	15.0	80	150
1.00	White	Plain	³0.096	³13.9	220	20.4	80	150
3.00	White	Plain	³0.070	³10.2	300	28.3	81	155
5.00	White	Plain	³0.058	³8.5	400	40.9	81	160
0.45	Black	Grid	³0.22	³32.7	50	5.0	78	135
0.80	Black	Grid	³0.10	³14.9	170	15	80	145
0.45	Green	Grid	³0.22	³32.7	50	5.0	78	135
0.80	Green	Grid	³0.10	³14.9	170	15	80	145

Attribute name	Attribute value
Pack Size	100
Media	MCE/Mixed Cellulose Esters
Diameter	47mm
Pore Size	0.8um
Surface	Grid
Colour	White
Type	Non-Sterile
