Specification | Materials |
▸ Power: DC12V, 1.0A ▸ Max. vacuum: 313 mbar abs. ▸ Max. liquid flow rate: 0.5 L/min ▸ Motor: 12W Brushless DC Motor ▸ Hose barb: ID6 ▸ Material contact with filtrate: SS316, FKM, Silicone, PP, PA66 ▸ Adaptor: Spin-lock | ▸ Housing material – SS304 ▸ Adaptor – SS316 ▸ Valve plate – EPDM (Ethylene Propylene Diene Monomer) ▸ Diaphragm – EPDM (Ethylene Propylene Diene Monomer) ▸ Fluid Path Inlet – SS316 ▸ Fluid outlet port – SS316 ▸ Fluid path hose – Silicone tube ▸ O-ring – FKM ▸ Draining hose – silicone |
WaterVac Filtration System Features:
◆ Save 70% bench space
The compact design of WaterVac 100 vacuum filtration system can save much bench space by simplifying procedure and tools needed in membrane filtration method.
◆ Improve operation time
Direct drainage design saves a lot of time to empty waste bottle and make the filtration more efficient.
◆ Easy Operation
Simply put on membrane on filter holder and push on/off button to start filtration easily.
◆ Versatile
Replaceable funnel base design makes it compatible with various kinds of filter holder.
◆ Compatible with Rocker SF funnel
WaterVac 100-MB can accept Rocker SF funnel – 100 / 300 / 500 ml. SF funnel is made of SS316 stainless steel which can be fast sterilized by flame.
WaterVac Filtration System Applications:
◆ MF Technique for analyzing aqueous-based fluids for microbial contamination.
◆ Suspended Solid test for municipal, surface, ground and drinking water.
◆ General filtration which no need to collect filtrate
