• Digital LCD display of both rotation speed and heating temperature allows for optimal control of all distillation processes
• Automatic motor lift releases the evaporating flask to a safe position in case of power failure
• 5L heating bath with wide temperature range from room temperature to 180°C Water/oil heating mode can be changed only through a switch
• Overheating protection temperature at 220 °C
• Boil-dry protection, automatically power off if heating without water/oil in the heating bath
• Speed range from 20 to 280rpm, and interval operation in clockwise and anticlockwise directions for drying process
• Condenser (cooling surface 1700cm²) with excellent cooling effect
• Ejection mechanism ensures easy removal of evaporating flask
• Patented double spring sealing ring made of PTFE provides an excellent sealing performance
• Optional glassware with explosion proof film available
PRODUCT PARAMETERS |
Cat.No. | 6030110111 |
Evaporating flask volume | 50-3000mL |
Temperature range | |
Temperature control accuracy | water: ± 1℃ ;oil: ±3℃ |
Speed range | 20-280rpm |
Direction of Rotation | Clockwise and counterclockwise |
Evaporation capacity | 1.56L/h |
Ultimate vacuum | - |
Temperature control | Micro processer PID control |
Display | LCD |
Timer | Yes |
Time Setting Range | 1-999min |
Lifting mode | Motorized |
Lifting stroke | 150mm |
Heating bath size | - |
Motor Type | Brushless DC motor |
Heating Power | 1300W |
Power | 1400W |
Voltage/Frequency | 100-120/200-240V,50/60Hz |
Dimension[D×W×H] | 465×457×583mm |
Weight | 15kg |
Permissible ambient temperature | 5-40℃ |
Permissible ambient humidity | ≤80% RH |
Protection Class | |
USB Interface | Yes |
Safety features | Motor over-current protection, earth-leakage protection lifting overload protection, Boil-dry protection, Overheating protection |
Applications | Chemical research, pharmaceutical manufacturing, food processing, cosmetics manufacturing, and chemical laboratories. |
