HPTLC plates RP-18 W/UV254, 5x20 cm 811073

TLC/HPTLC precoated plates RP-18 W/UV 254 size: 5x20 cm pack of 50
SKU: 811073
Manufacturer: Machery Nagel



TLC/HPTLC precoated plates RP-18 W/UV 254 size: 5x20 cm pack of 50





TLC/HPTLC glass plates coated with a partial octadecyl (C18, ODS) modification, wettable with water. Based on silica gel 60. Particle size of analytical plates: 2–10 µm. Indicator - acid-resistant product with a pale blue fluorescence for short-wave UV (254 nm). UV-absorbing substances apppear as dark-blue to black spots on a light-blue background. Normal phase or reversed phase separation modes are possible with eluents from anhydrous solvents to mixtures with high concentrations of water. The relative polarity of the eluent determines the polarity of the layer. Order of polarity - silica > DIOL > NH2 > CN > RP-2 > C18-50 > RP-18 W > C18-100

Hazardous materialNo
MethodThin layer chromatography (HPTLC/TLC)
BrandRP-18 W
PhaseRP-18 W UV254
Base materialGlass plates coated with silica gel
Surface chemistrySilica gel with octadecyl (C18, ODS, RP18) modification
ModeReversed phase (RP)
Plate size5x20 cm
Layer thickness0.25 mm
Layer hardnessStandard, soft
UV indicatorYes
Support material / backingGlass
Particle size2–10 µm
Particle typeFully porous particles (FPP)
Particle shapeIrregular
Pore size60 Å
Pore volume0.75 mL/g
BinderYes
pH stability2.0–10.0
Recommended application(s)Aminophenols, Barbiturates, HPTLC, Nucleobases, Phthalates, Plasticizers, Polycyclic aromatic hydrocarbons (PAH), Preservatives, Reversed phase (RP), Steroids, Tetracyclines, Wettable with water
Temperature stabilityHigh
Storage temperatureRT
Scope of delivery50x HPTLC/TLC glass plates (5x20 cm)
